Specification:
Description:
Materials
Outer layer：93%Nomex (*),5%Kelver,2%Anti-Static(P140)(220g/m²)
Moisture barrier:PTFE Waterproof and Moisture Permeable(120g/m²)
Thermal barrier：80% Aramid Nomex,20%Kevlar (75g/m²)
ComfortLayer:50%M-aramid,50%P-aramid.(120g/m²)
Anti-wicking fabric: Nomex with chloroprene rubber coating, 450g/m2
Zipper: Metal
Sewing thread: Aramid
Reflective tape: 3M aramid flame retardant reflective tape
Thread: Knitted Aramid
Knee pad material: Aramid with fire resistant PU coating, 360g/m2
(*)Nomex IIIA is mainly composed of 93% Nomex, 5% Kevlar and 2%
antistatic fiber
Color
Kahki,Orange.Navy Blue,Yellow
Levels
Xf2 Xr2 Y2 Z2
Technical Parameters
*Size:M/L/XL/XXL/XXXL
*Weight:2700g
*Tpp(Cal/cm²):35Cal
*Buring testing: continue burning time = 0 second, damage length s26
mm
*Thermal stability testing: 260+5 ℃ for 5 minutes the contraction
*percentage <1%
*Shrinkage testing: after 5 times wash, Shrinkage <0.9%
*Breaking testing: breaking strength radial = 1380 N;
*breaking strength latitudinal = 970.4N
*Tearing force testing: tearing force radial = 398.2 N;
*tearing force latitudinal =374.3N
*Water proof and Chemical penetration resistance.
*Aramid non-woven fabric and PTFE Material composited, 110 gr/m2.
*ATPV(Arc Thermal Protective Value) 15 Cal/cm2, Certified to HRC 2.
*Burin testing: continue burning time = 0 second, damage length <50 mm
*Thermal stability testing: 260+5 ℃ for 5 minutes, the contraction
percentage <1%
*Shrinkage testing: after 5 times wash, Shrinkage <1.0%
*Moisture permeability: 7075g/(m2*24Hour) Resistance to static water
pressure: >50 kPa
*oil resistance: Level 3
*Thread heat resistance for sewing thread (shall not melt, drip, separate or
ignite) continue burning time = 0 second, damage length s26 mm
*Water absorption resistance test for outer shell and collar linings and shall
not have more than 30% water absorption.
Applications
Structural fire protection, fire training, fire rescue.Etc
Size
M/L/XL/XXL/XXXL/XXXXL
Competitive
Advantage
*Tear-resistant plaid fabric
*Adjustable cuffs
*Front closed by heavy duty FR Plastic zipper and FR Velcro
*FR yellow silver yellow reflective hole tape in 2inch width 3M Scotchlite
*FR drainage mesh into waist hem and bottom pocket
*Knitted Aramid cuffs with thumb Loop
*Extra layers and abrasion resistant design in neck, waist, and elbows.
*Velcro waist size adjustment
*X-type Adjustable strap
*Thickened Kevlar process at the elbows, knees
*3D pocket design, and retain drainage holes
*Customizable back reflective characters with “FIRE”
*The sleeves have a protective wristband permanently fixed to the jacket
sleeve ensuring there are no gaps in thermal protection.
*The jacket has horizontal reflective strips on the chest and two vertical
reflective strips on the back.
*Waterproof hem design
*Leather black water-stop fabric on bottom of trousers
*Plastic zippers at the bottom of the trouser which should be concealed
so that the gumboot can be worn easily
